Key features:
1. A DC load output port
2. An optional battery temperature sensor ensures precise battery charging
3. LED displays to indicate the status of charge
4. Lightning protection
5. Reverse current at night
6. Three-stage battery charging (bulk, absorption, and float) with optional temperature compensation
7. Automatic overload protection
8. Microprocessor controlled
9. Silent, pulse width modulated (PWM), high efficiency operation
Technical specifications:
Rated voltage |
12/24VDC |
24VDC |
48VDC |
|||
Rated charge current(include load current) |
40Amp/60Amp |
40Amp |
40Amp |
|||
Load current |
10Amp |
|||||
Input voltage range |
15-45V/30-70VDC |
30-100VDC |
60-100VDC |
|||
Max. PV open circuit array voltage |
45V/70VDC |
100VDC |
100VDC |
|||
Overload protection(DC load) |
2.0 * Inom>5s 1.5 * Inom>20s 1.25 * Inom temperature controlled |
|||||
Typical idle consumption |
At idle<10mA |
|||||
Bulk charge |
14.6VDC(default) |
29.2VDC(default) |
58.4VDC(default) |
|||
Floating charge |
13.4VDC(default) |
26.8VDC(default) |
53.6VDC(default) |
|||
Equalization charge |
14.0VDC(default) |
28.0VDC(default) |
56VDC(default) |
|||
Over charge disconnection |
14.8VDC |
29.6VDC |
59.2VDC |
|||
Over charge recovery |
13.6VDC |
27.2VDC |
54.4VDC |
|||
Over discharge disconnection |
10.8VDC(default) |
21.6VDC(default) |
43.2VDC(default) |
|||
Over discharge reconnection |
12.3VDC |
24.6VDC |
29.2VDC |
|||
Temperature compensation |
-13.2mV/'C |
-26.4mV/'C |
-52.8mV/'C |
|||
Lead acid battery settings |
Adjustable |
|||||
NiCad battery settings |
Adjustable |
|||||
Load control mode |
1. Low voltage reconnect (LVR): adjustable 2. Low voltage disconnect (LVD): automatic disconnection 3. Reconnection: includes warning flash before disconnect and reconnection |
|||||
Low voltage reconnect |
12.0-14.0VDC |
24.0-28.0VDC |
48.0-56.0VDC |
|||
Low voltage disconnect |
10.5-12.5VDC |
21.0-25.0VDC |
42.0-50.0VDC |
|||
Ambient temperature |
0 |
|||||
Altitude |
Operating |
|||||
Protection class |
IP21 |
|||||
|
BTS-optional remote battery temperature sensor for increased charging precision |
|||||
Terminal size(fine/single wire) |
#8AWG |
