X Series 1000W to 12kW Pure Sine Wave Inverter

Item

Model

1.0kW

1.5kW

2.0kW

3.0kW

4.0kW

5.0kW

6.0kW

8.0kW

10.0kW

12.0kW

Inverter output

Continuous output power

1.0kW

1.5kW

2.0kW

3.0kW

4.0kW

5.0kW

6.0kW

8.0kW

10.0kW

12.0kW

Surge rating(20ms)

3.0kW

4.5kW

6.0kW

9.0kW

12.0kW

15.0kW

18.0kW

24.0kW

30.0kW

36.0kW

Output waveform

Pure sine wave/same as input(bypass mode)

Nominal efficiency

>88%(peak)

Line mode efficiency

>95%

Power factor

0.9-1.0

Nominal output voltage rms

100-110-120VAC/220-230-240VAC

Output voltage regulation

±10% rms

Output frequency

50Hz ± 0.3Hz/60Hz ± 0.3Hz

Short circuit protection

Yes(1s after fault )

Typical transfer time

10ms(Max)

THD

< 10%

DC input

Nominal input voltage

12.0VDC/24.0VDC/48.0VDC

24.0VDC/48.0VDC

48.0VDC

Minimum start voltage

10.0VDC/10.5VDC for 12VDC mode

*2 for 24VDC, *4 for 48VDC;

Low battery alarm

10.5VDC/11.0VDC for 12VDC mode

Low battery trip

10.0VDC/10.5VDC for 12VDC mode

High voltage alarm

16.0VDC for 12VDC mode

Low battery voltage recover

15.5VDC for 12VDC mode

Idle consumption-search mode

< 25W when power saver on(refer to table )

Charger

Output voltage

Depends on battery type(refer to Table 2.5.2)

Charger breaker rating

10A

15A

20A

20A

20A

30A

30A

40A

40A

40A

Max charge power rate

1/3 rating power(refer to Table 2.5.3)

Battery initial voltage for start

10-15.7VDC for 12VDC mode

*2 for 24VDC, *4 for 48VDC;

Over charge protection S.D.

15.7VDC for 12VDC mode

BTS

Battery temperature sensor

(optional)

 Yes(refer to the table)

Variances in charging voltage & S.D voltage base on the battery temperature

Bypass & protection

Input voltage waveform

Sine wave(grid or generator)

Nominal voltage

110VAC

120VAC

220VAC

230VAC

230VAC

Max input AC voltage

150VAC for 120VAC LV mode; 300VAC for 230VAC HV mode

Nominal input frequency

50Hz or 60Hz

Low frequency trip

47±0.3Hz for 50Hz, 57±0.3Hz for 60Hz

High frequency trip

55±0.3Hz for 50Hz, 65±0.3Hz for 60Hz

Overload protection(SMPS load)

Circuit breaker

Output short circuit protection

Circuit breaker

Bypass breaker rating

10A

15A

20A

30A

40A

40A

40A

50A

63A

63A

Transfer switch rating

30 Amp for UL & TUV

40 Amp for UL

80 Amp for UL

Bypass without battery connected

Yes(optional)

Max bypass current

30 Amp

40 Amp

80 Amp

Solar Charger

(Optional)

Rated voltage

12VDC/24VDC/48VDC

Solar input voltage range

15-30VDC/30-55VDC/55-100VDC

Rated charge current

40~60A

Rated output current

15A

Self consumption

< 10mA

Bulk charge(default)

14.5VDC for 12VDC mode

( *2 for 24VDC, *4 for 48VDC)

Floating charge(default)

13.5VDC for 12VDC mode

Equalization charge(default)

14.0VDC for 12VDC mode

Over charge disconnection

14.8VDC for 12VDC mode

Over charge recovery

13.6VDC for 12VDC mode

Over discharge disconnection

10.8VDC for 12VDC mode

Over discharge reconnection

12.3VDC for 12VDC mode

Temperature compensation

-13.2mV/'C for 12VDC mode

Ambient temperature

0~40'C (full load), 40~60'C (derating)

Mechanical specifications

Mounting

Wall mount

Inverter dimensions(L*W*H)

388*415*200mm

488*415*200mm

588*415*200mm

Inverter weight(solar charger)Kg

21+2.5

22+2.5

23+2.5

27+2.5

38+2.5

48+2.5

49+2.5

60+2.5

66+2.5

70+2.5

Shipping dimensions(L*W*H)

550*520*310mm

650*520*310mm

750*520*310mm

Shipping weight(solar charger)Kg

23+2.5

24+2.5

25+2.5

29+2.5

40+2.5

50+2.5

51+2.5

62+2.5

68+2.5

72+2.5

Display

Status LED/status LED+LCD

Standard warranty

2 years(optional)
